What is confirmed for this product?

L-Shape Foldable Bar Counter for Wine Bar, Water Resistant Steel is recorded under bar counter. The product record lists the material as Metal. Product images are used as appearance and layout references; unlisted technical specifications are not inferred from photographs.

What should be sent before fabrication?

Send the selected product, drawings or site photos, dimensions, quantity, finish direction, access conditions and destination. Final engineering details are confirmed before fabrication.

Can this product be supplied for an OEM/ODM project?

The factory can review OEM/ODM requirements after the product scope, drawings, finish and project conditions are confirmed.

Commercial Stainless Steel Bar Counter Station Custom (RM-026)

The RM-026 is a heavy-duty commercial stainless steel bar counter station custom-engineered for luxury hotel lounges, high-volume cocktail bars, rooftop venues, and private entertainment suites. Fabricated from certified prime SUS 304 food-grade stainless steel with fully integrated drop-in insulated ice bins, speed rails, integrated drainage channels, and under-counter refrigerated storage.

Custom dimensional length and layout; food-grade SUS 304 construction (1.5mm–2.0mm worktops); integrated insulated ice wells with drainage; modular electrical and plumbing chase pathways.

OEM/ODM: OEM/ODM factory customization: send drawings, dimensions, finish direction and branding requirements for model and project confirmation.

Certified SUS 304 Food-Grade Construction: 1.5mm–2.0mm heavy-gauge stainless steel worktop and chassis with marine-edge spill containment — Immune to acidic fruit juices, spirits, and daily commercial sanitizing chemicals

Integrated Insulated Cocktail Ice Well: Double-walled polyurethane-insulated drop-in ice chest with speed rails and continuous drain — Keeps crushed and cubed cocktail ice frozen for 12+ hours without external power

Modular Ergonomic Under-Counter Architecture: Configurable layouts accommodating glass chillers, blender stations, and lockable liquor storage — Maximizes bartender efficiency and accelerates service speed during peak dining hours

Architectural PVD Titanium Decorative Facings: Optional decorative front panels in Champagne Gold, Rose Gold, Brushed Bronze, or custom stone reveals — Blends industrial back-of-house durability with front-of-house luxury aesthetics

Commercial Bartender Ergonomics & High-Volume Workstation Design

Behind every successful luxury hotel bar or high-energy cocktail lounge lies an ergonomically engineered bar workstation. The RM-026 is developed in collaboration with commercial hospitality operators to minimize unnecessary bartender steps and repetitive strain.

The workstation layout positions high-frequency tools within arm’s reach: a centrally located 100-bottle insulated ice well flanked by dual bottle speed rails, recessed blender stations with GFI electrical conduits, and dedicated glass washing dump sinks with integrated perforated drying grids.

Heavy-Duty SUS 304 Metallurgy & Marine-Edge Spill Containment

Commercial bar counters face continuous exposure to acidic citrus juices, high-proof alcohol spills, heavy glassware impacts, and aggressive chemical sanitizers. Low-grade 201 or 430 stainless steel quickly pits, discolors, and rusts under these conditions.

ROYAL METAL fabricates all work surfaces exclusively from certified prime 1.5mm to 2.0mm SUS 304 stainless steel. The main worktop features a seamless 15mm raised marine anti-drip edge around the entire perimeter, preventing liquid overflow onto finished flooring.

Under-Counter Refrigeration Integration & MEP Chase Plumbing

The RM-026 modular sub-structure is pre-engineered with internal utility chase channels (100mm × 100mm) running longitudinally beneath the work surface. This allows electrical wiring, beverage soda lines, beer python trunk lines, and potable water piping to route cleanly without visible floor clutter.

Under-counter bays are precisely dimensioned to accept self-contained back-bar bottle coolers, commercial glass frosters, or custom refrigerated drawer units operating on dedicated 220V/50Hz or 110V/60Hz circuits.

Custom Architectural Dimensional Sizing & Front Elevation Finishes

• Standard Worktop Depth: 650mm to 800mm (customizable to fit narrow architectural footprints).

• Working Height: 850mm to 920mm ergonomically optimized for commercial bar stools and standing staff.

• Front Bar Facings: Structural stainless steel mounting framework ready to accept client-supplied marble, fluted timber, back-lit translucent onyx, or ROYAL METAL laser-cut PVD decorative metal screens.

• Sinks & Plumbing: NSF-compliant seamless deep-drawn stainless steel sink bowls with commercial gooseneck faucets and removable basket strainers.

Factory Pre-Assembly & Export Packaging Standards

To ensure zero on-site welding or fitting issues, every custom RM-026 bar station undergoes complete factory trial assembly in our 6,600 m² Foshan facility. Water drainage lines are pressure-tested and sectional interlocking joints are verified prior to dismantling into modular crated sections.

All components are wrapped in heavy polyethylene film, pearl cotton edge guards, and crated in heavy-duty 18mm ISPM-15 plywood crates for secure worldwide ocean shipment.
